WebGL 2 Development with PicoGL.js

Tarek Sherif

BioDigital

WebGL 2 is a BIG Update

• New shading language
• Vertex array objects
• Uniform buffer objects
• Instanced drawing
• Transform feedback
• Multiple render targets
• Query objects
• etc, etc, etc...

How to get started?

PicoGL.js

• Just simplify management of the rendering layer
  • No math, scene graph, physics, etc.
• User manipulates GL constructs
  • Programs, VAOs, UBOs, transform feedbacks, queries, etc.
• PicoGL.js just provides a friendly API, helps with layout and works around implementation bugs

PicoGL.js 101


  // App manages global GL state
  var app = PicoGL.createApp(canvas)
  .clearColor(0.0, 0.0, 0.0, 1.0);

  // Program, VBO, VAO
  var program = app.createProgram(vertexShaderSource, fragmentShaderSource);
  var positions = app.createVertexBuffer(PicoGL.FLOAT, 2, positionData);
  var vertexArray = app.createVertexArray()
  .vertexAttributeBuffer(0, positions);

  // Draw call manages per-draw state
  var drawCall = app.createDrawCall(program, vertexArray);

  app.clear();
  drawCall.draw();



Vertex Array Objects

• In WebGL 1, to manage geometry for each frame you have to:
  • Bind your buffers
  • Set up the vertex attribute pointer
  • Enable the attribute pointer
• In WebGL 2, you bind your buffers and set up pointers on a vertex array object (VAO)
  • Then for each frame, you just bind the VAO

Vertex Array Objects


  gl.bindVertexArray(vertexArray);
  gl.bindBuffer(gl.ARRAY_BUFFER, positionBuffer);
  gl.vertexAttribPointer(0, 3, gl.FLOAT, false, 0, 0);
  gl.enableVertexAttribArray(0);

  gl.bindBuffer(gl.ARRAY_BUFFER, normalBuffer);
  gl.vertexAttribPointer(1, 3, gl.FLOAT, false, 0, 0);
  gl.enableVertexAttribArray(1);
  gl.bindVertexArray(null);

  function draw() {
      gl.bindVertexArray(vertexArray);
      gl.drawArrays(gl.TRIANGLES, 0, numVertices);

      requestAnimationFrame(draw);
  }



Vertex Array Objects


  var vertexArray = app.createVertexArray()
  .vertexAttributeBuffer(0, positionBuffer)
  .vertexAttributeBuffer(1, normalBuffer);

  app.createDrawCall(program, vertexArray);

  function draw() {
      drawCall.draw()

      requestAnimationFrame(draw);
  }



Vertex Array Objects

• Reduces CPU overhead per draw call
• Generally simplifies code

Uniform Buffer Objects

• In WebGL 1, you have to update each uniform individually by sending data to the GPU.
• In WebGL 2, you can store all your uniform values in a uniform buffer object and then just bind it to update all uniform values at once.
  • WARNING: To do this manually, you have to align uniform variables in buffer memory according to the STD140 layout!

Uniform Buffer Objects


  var uniformsLocation = gl.getUniformBlockIndex(program, "myUniforms");
  gl.uniformBlockBinding(program, uniformsLocation, 0);

  // HAVE TO KNOW STD140 LAYOUT!!!
  var uboData = new Float32Array(24);
  uboData.set(viewProjMatrix);
  uboData.set(eyePosition, 16);
  uboData.set(lightPosition, 20);

  var uniformBuffer = gl.createBuffer();
  gl.bindBufferBase(gl.UNIFORM_BUFFER, 0, uniformBuffer);
  gl.bufferData(gl.UNIFORM_BUFFER, uboData, gl.STATIC_DRAW);



Uniform Buffer Objects


  // PicoGL.js handles layout.
  var uniformBuffer = app.createUniformBuffer([
      PicoGL.FLOAT_MAT4,
      PicoGL.FLOAT_VEC4,
      PicoGL.FLOAT_VEC4
  ])
  .set(0, viewProjMatrix)
  .set(1, eyePosition)
  .set(2, lightPosition)
  .update();

  drawCall.uniformBlock("myUniforms", uniformBuffer);



Uniform Buffer Objects

• Can significantly reduce overhead for updating uniforms

Transform Feedback

• Capture output from the vertex shader to use as input for the next frame
• Not available in WebGL 1
  • (Can be emulated by writing vertex shader output to float textures)

Transform Feedback


  var program = gl.createProgram();
  gl.attachShader(program, vertexShader);
  gl.attachShader(program, fragmentShader);
  gl.transformFeedbackVaryings(program, ["vPosition"], gl.SEPARATE_ATTRIBS);
  gl.linkProgram(program);

  var positionBufferA = gl.createBuffer();
  gl.bindBuffer(gl.ARRAY_BUFFER, positionBufferA);
  gl.bufferData(gl.ARRAY_BUFFER, positionData, gl.STREAM_COPY);

  var positionBufferB = gl.createBuffer();
  gl.bindBuffer(gl.ARRAY_BUFFER, positionBufferB);
  gl.bufferData(gl.ARRAY_BUFFER, positionData.byteLength, gl.STREAM_COPY);


  gl.bindBuffer(gl.ARRAY_BUFFER, positionBufferA);
  gl.vertexAttribPointer(0, 3, gl.FLOAT, false, 0, 0);
  gl.enableVertexAttribArray(0);

  gl.bindBufferBase(gl.TRANSFORM_FEEDBACK_BUFFER, 0, positionBufferB);

  gl.beginTransformFeedback(gl.TRIANGLES);
  gl.drawArrays(gl.TRIANGLES, 0, numVertices);
  gl.endTransformFeedback();



Transform Feedback


  var program = app.createProgram(vertexShader, fragmentShader, ["vPosition"]);

  var positionBufferA = app.createVertexBuffer(PicoGL.FLOAT, 3, positionData);
  var positionBufferB = app.createVertexBuffer(PicoGL.FLOAT, 3, positionData.length);

  var vertexArray = app.createVertexArray()
  .vertexAttributeBuffer(0, positionBufferA)

  var transformFeedback = app.createTransformFeedback()
  .feedbackBuffer(0, positionBufferB);

  var drawCall = app.createDrawCall(program, vertexArray)
  .transformFeedback(transformFeedback);

  drawCall.draw();



Transform feedback

• Allows you to push animation logic to the GPU
• Major win for animations
• Particle System
• Wandering Triangles

Instanced Drawing

• It's common to draw the same geometry multiple times while changing uniform values
  • E.g. transform, color
• In WebGL 1, you have to iterate over each object and draw it individually
• In WebGL 2, you can draw objects that share geometry in a single draw call

Instanced Drawing


  var positionBuffer = gl.createBuffer();
  gl.bindBuffer(gl.ARRAY_BUFFER, positionBuffer);
  gl.bufferData(gl.ARRAY_BUFFER,  positionData, gl.STATIC_DRAW);
  gl.vertexAttribPointer(0, 3, gl.FLOAT, false, 0, 0);
  gl.enableVertexAttribArray(0);

  var colorBuffer = gl.createBuffer();
  gl.bindBuffer(gl.ARRAY_BUFFER, colorBuffer);
  gl.bufferData(gl.ARRAY_BUFFER,  colorData, gl.STATIC_DRAW);
  gl.vertexAttribPointer(1, 3, gl.FLOAT, false, 0, 0);
  gl.enableVertexAttribArray(1);
  gl.vertexAttribDivisor(1, 1);

  gl.drawArraysInstanced(gl.TRIANGLES, 0, numVertices, numInstances);



Instanced Drawing


  var positionBuffer = app.createVertexBuffer(PicoGL.FLOAT, 3, positionData);
  var colorBuffer = app.createVertexBuffer(PicoGL.FLOAT, 3, colorData);

  var vertexArray = app.createVertexArray()
  .vertexAttributeBuffer(0, positionBuffer)
  .instanceAttributeBuffer(1, colorBuffer);

  var drawCall = app.createDrawCall(program, vertexArray);
  drawCall.draw();



Instanced Drawing

• Reduced CPU overhead for drawing instances
• 64,000 Cubes
• 125,000 Cubes (with transform feedback)

Multiple Render Targets

• In WebGL 1, you have to do a separate draw call for every framebuffer target you want to draw to
• In WebGL 2, you can bind multiple targets to a single framebuffer and draw to all of them in one draw call

Multiple Render Targets


  var framebuffer = gl.createFramebuffer();
  gl.bindFramebuffer(gl.FRAMEBUFFER, framebuffer);

  var target1 = gl.createTexture();
  gl.bindTexture(gl.TEXTURE_2D, target1);
  gl.texParameteri(gl.TEXTURE_2D, gl.TEXTURE_MIN_FILTER, gl.NEAREST);
  gl.texStorage2D(gl.TEXTURE_2D, 1, gl.RGBA8, gl.drawingBufferWidth, gl.drawingBufferHeight);
  gl.framebufferTexture2D(gl.FRAMEBUFFER, gl.COLOR_ATTACHMENT0, gl.TEXTURE_2D, target1, 0);

  var target2 = gl.createTexture();
  gl.bindTexture(gl.TEXTURE_2D, target2);
  gl.texParameteri(gl.TEXTURE_2D, gl.TEXTURE_MIN_FILTER, gl.NEAREST);
  gl.texStorage2D(gl.TEXTURE_2D, 1, gl.RGBA8, gl.drawingBufferWidth, gl.drawingBufferHeight);
  gl.framebufferTexture2D(gl.FRAMEBUFFER, gl.COLOR_ATTACHMENT1, gl.TEXTURE_2D, target2, 0);

  gl.drawBuffers([
      gl.COLOR_ATTACHMENT0,
      gl.COLOR_ATTACHMENT1
  ]);



Multiple Render Targets


  var framebuffer = app.createFramebuffer()
  .colorTarget(0)
  .colorTarget(1);



Multiple Render Targets

• Much more efficient post-processing pipelines
• Deferred Renderer
• Screen Space Ambient Occlusion
• Motion Blur

Other Examples

• Depth of Field
• Occlusion Culling
• Cloth

Thanks!

• Website: tsherif.github.io/picogl.js/
• GitHub: github.com/tsherif/picogl.js
• Twitter: @thsherif
• Email: tarek@biodigital.com
